| Attribute | Value |
|---|---|
| Environmental Requirements | Clean environment with no pollutant sources, TVOC ≤500μg/m³ |
| Temperature Range | 10~40℃ (high temperature cleaning up to 250℃) |
| Humidity Range | 40~70% R.H (20℃~30℃) |
| Pressure | 10±5pa |
| Product Model | V-50 | V-100 | V-250 | V-500 | V-1000A | V-1000B | V-2000 |
|---|---|---|---|---|---|---|---|
| Chamber Volume (W×D×H cm) | 56×30×30 | 63×40×40 | 70×60×60 | 102×70×70 | 158×80×80 | 91×100×110 | 200×110×90 |
| Starting Power | 5kW | 6kW | 8kW | 10kW | 15kW | 15kW | 20kW |
| Operating Power | 3kW | 3.4kW | 5kW | 6kW | 7kW | 7kW | 9kW |
| Temperature Fluctuation | ±0.3℃ |
| Temperature Deviation | ±0.5℃ |
| Humidity Fluctuation | ±2.5% R.H |
| Humidity Deviation | ±3% |
| Air Exchange Rate | 0.2~5/h ±5% (optional 0.2~3/h ±5%) |
| Air Velocity | 0.1m/s - 0.3m/s |
| Recovery Rate | >80% for formaldehyde, octanol, 4-phenyl cyclohexene, dodecane, tetradecane |
| Clean Air System | Standard configuration |
| Background Concentration | Single VOC <2μg/m³, TVOC <20μg/m³ |
|
|
